Introduction of Imatest Master Software
Imatest provides customers with software, charts and equipment to meet and exceed image quality testing standards.
Imatest gives companies the right tools to test their image capture technology and has been a leader in image quality testing for over 10 years. Whether it’s still shots or video, visible light or infrared, Imatest has helped businesses in a variety of industries, including mobile, automotive, medical and manufacturing.
Imatest Master
Reinventing the standards for image quality testing
Why bother creating in-house testing software, when Imatest Master handles virtually all image quality testing needs in one tidy software package? Test everything from sharpness and distortion to color and illumination with the various modules included with Master’s software package.
Comprehensive image quality testing
Test everything from sharpness and distortion to color and illumination with Imatest Master.
R&D Solutions |
Featured Modules |
|
Analyze over 30 popular test charts with different features for color, tone, sharpness, noise and many other image quality factors. |
SFRplus: Assess many image quality factors using one specially designed test chart. |
|
Faster, more efficient and more reliable than creating in-house software. |
eSFR ISO: Assess many image quality factors from enhanced versions of the ISO 12233:2014 test chart. |
|
Test for a variety of image quality factors at once using SFRplus or eSFR ISO, and reduce the amount of time spent switching between charts |
SFR: Inspect any slanted edge feature. |
|
Multicharts: Analyze color, tone, and noise from a wide variety of test charts. |
||
Rescharts: Evaluates several resolution test charts |
||
Dot Pattern: Measure distortion and lateral chromatic aberration using a dot chart. The calculation is CPIQ-compliant. |
||
Even Field Test: Detect blemishes and defective pixels on the sensor and measures color and illumination uniformity. |
4.0 Features & Enhancements |
5.0 Features & Enhancements |
5.1 New Features and Enhancements |
||
eSFR ISO: highly automated analysis of ISO 12233:2014 Edge SFR chart |
Image Acquisition: Image acquisition capabilities added to Imatest Master. See our full list of supported hardware |
MTF Compensation: MTF Compensation reduces the impact of the chart on measured imaging system MTF |
||
Automatic region detection available for: X-Rite Colorchecker, 36-Patch Dynamic Range |
Imatest Database: Track numerous testing sessions in a convenient web application |
Geometric Calibration: Imatest produces a geometric calibration from a projective camera model and images of checkerboard patterns |
||
With added registration marks: Spilled Coins/Dead Leaves, Log Frequency-Contrast (with added registration marks), ISO 14524, ISO 15739, Siemens Star |
Imatest Test Manager: Organize a set of modules to run with user-defined test plans |
Sony AYA Image Acquisition: Direct image acquisition from Sony sensor development boards through the Sony AYA software tool |
||
Main window redesign |
Imatest Reports: Generate interactive reports to efficiently analyze data outputs |
Image Processing: Synthetic raw creation/Remosaic: Generate interactive reports to efficiently analyze data outputs |
||
Video file reading ability: extracts still frames from AVI and MP4 files |
Arbitrary Charts: Combine the features you need to analyze in a single test chart |
Improved distortion calculation: Checkerboard and SFRplus modules support an enhanced set of distortion models, and provide faster and more accurate distortion coefficient and center of distortion estimations |
||
ISO 15739:2013 visual noise calculations |
Image Statistics Viewer: Examine a number of image properties including cross-sections, square regions, histograms, Fourier spectrum, distance between points, and EXIF data |
Temporal noise from multiple files now available in Multicharts and Multitest: Now compliant with ISO 15739‘s temporal noise measurement |
||
Pass/Fail monitor: shows pass/fail status for all modules |
Multi-Wedge Plot: Provides multiple regions of interest (ROI) for the analysis of multiple wedge plots on an eSFR ISO test chart. |
|
||
Image Processing Module: Read, process, and save batches of images by reading a batch of several images rather than one individual image |
||||
SFRreg Center Chart: Analyze MTF measurements near the camera’s center field of view on ultra-wide cameras as well as tonal response, noise, and color measurements |
Sensor Evaluation Boards
Capture Interfaces
For more information about the lighting system and its many options, please contact us. If you would like to learn more about a complete lab setup, please visit our Image Quality Lab Setup page.
