Color Asessment Light box

  • Brand:ColorSpace
  • Model:CS-iseeCOLOR
  • Product description: CS-ISEECOLOR Color Shooting Box is the latest multi-spectral light source color shooting box launched by ColorSpace. It can truly restore the color effect of the shooting object, and is suitable for c
  • INQUIRY

The CS-iseeCOLOR Color Assessment Light Box is a state-of-the-art color assessment light box recently introduced by ColorSpace Co., Ltd. It offers a "What You See Is What You Get" experience that can truly reproduce the colors captured.

CS-iseeColor is an innovative non-contact color measurement system developed by ColorSpace Co., Ltd, designed to meet the high demands for color accuracy and consistency in modern industry. It combines the latest imaging technology with advanced algorithms to provide a fast, accurate, and user-friendly color assessment solution. The iseeColor is not only capable of measuring color but also analyzing texture and gloss, offering a more comprehensive product quality evaluation.

It can be used for color analysis and quality control in various industries such as textiles, cosmetics, plastics, building materials, jewelry, food, and beverages, particularly providing an excellent solution for products with irregular shapes and complex patterns.

色彩拍摄光箱
珠宝拍摄光箱

The CS-iseeColor test system is equipped with a built-in drawer-style object platform, featuring a silent drawer opening and closing design. It includes an internal imaging system and has high-precision color correction capabilities. When the drawer is closed, the internal lighting environment is unaffected by external light conditions. The touch screen can store up to 80 sets of lighting conditions.

Product Hardware Features:

1. Non-contact Measurement: Prevents physical damage to samples.
2. High Efficiency: Quickly completes color and image measurement, enhancing quality control speed.
3. High Reproducibility: Ensures consistency and reliability in color measurement.
4. Easy to Operate: A user-friendly interface simplifies the learning curve.
5. Flexibility: Suitable for a variety of products and materials, including solids and liquids.
6. Data Sharing: Supports private or public cloud databases for easy supply chain communication.
7. Virtual Sample Function: Allows color assessment of different color schemes by transforming the base sample colors.
8. Multiple Box Options: Meets the measurement needs for samples of different sizes.
9. Optional 26-channel multispectral light source, capable of simulating various spectral lighting environments, with the addition of ultraviolet and infrared spectra. Supports the selection of hyperspectral cameras.
10. Open Ports, providing SDK for secondary development.

Software Features:

1. The software controls the camera for automatic shooting and captures images, which are then named and stored on the computer according to the settings.
2. A high-precision imaging color correction system that enables true color reproduction and analysis, with an average color difference of <3 (ΔE00, 24-color tile).
3. Image color recognition function, capable of analyzing the RGB/Lab/Yxy color values of selected areas in the captured images and recording and saving them.
4. Comparison can be made between specified standard colors and sample colors.
5. Preset testing conditions: Parameters for light sources, cameras, and lenses can be pre-stored for direct use during shooting.
6. Optional built-in spectral illuminance meter, capable of real-time spectral acquisition and closed-loop correction.

7. The multispectral version can perform spectral simulation matching and store it for later use, with options for ultraviolet and infrared spectra.

In conjunction with a professional monitor, it achieves what you see is what you get. The displayed colors are consistent with the true colors.

Supports multi-position shooting box to prevent overexposure of high-gloss surfaces.
Supports an optional rotating base for 3D modeling.
Supports an optional hyperspectral camera.

Sample images, including material textures and colors, can be stored in a database, made accessible for sharing within the company or for external customer access.


CS-iseeCOLOR Specification

参数

CS-ISEECOLOR色彩拍摄箱系列产品

Light Source Type

LED light

LED Channel Number

Multi-color temperature version / Multispectral version / Optional ultraviolet or infrared light source

Standard Light Simulation

Pre-stored standard light sources: A/H/D50/D65, the multispectral version supports importing custom spectrum

Illuminance Range

A light up to 15000 lux, D light up to 18000-20000 lux

Spectral Range

3380nm ~ 730nm, with an option for 360nm ~ 1500nm

Color Temperature Range


CCT: 2800K ~ 6500K ±100K, Multispectral version: 2000K ~ 20000K


CRI

A/H/D50/D65: >97~98

Light Emitting Area

423x386mm

Dimensions

iseeColor-01:500x450x500mm(L*W*H);iseeColor-02:1040mm × 740mm × 910mm(L*W*H)

Color

N7 Neutral color diffuse reflection material

Illuminance Meter

Spectral illuminance meter (optional), capable of real-time spectral acquisition and closed-loop correction

Control Method

Manual (standard): Touch screen control; Automatic (optional): USB control

SDK : Optional


Light Source Lifespan

>15000 Hours

Power Spply

AC 220V

Software

CS-Iseecolor

Device Configuration

Color shooting box X1;
Power cord X1;
Analysis software X 1.
